Product Portfolio · 8 Systems · 20 Products

Mapped to the
thermal profile of your plant

Select a service zone below. Each system carries lab-certified chemistry, full batch traceability, and variants engineered around real steel plant practice - not catalogue averages. Led by our flagship Tundish Covering Compound, supplied in both granular and powdered forms.

PIPL Flagship Product

Tundish Covering CompoundTCC

Unlike single-recipe imports, PIPL builds TCC in two physical forms - carbon-free silica granules (INSULEX-GS) and fast-spreading powder (INSULEX-PW) - across silica (acidic), basic CaO-MgO, alumina/neutral and ultra-low-carbon chemistries. Granules run low-dust and low-consumption; the basic grade (CaO 38-47%) saturates magnesia linings to extend tundish life; and the ULC grade (free carbon <= 0.2%) protects IF and clean steels from carbon pick-up. Every grade is lab-matched to your slag practice, not a catalogue average.

Granular TCC
Carbon-free silica granules
1 grade · Silica (Acidic)
Powdered TCC
Fast-spreading powder, multiple chemistries
4 grades · Silica / CaO-MgO / ULC / Neutral
Explore TCC grades & specs
Granular TCC

FORM 01 · PANCH INSULEX-GS

Granular TCC

Powdered TCC

FORM 02 · PANCH INSULEX-PW

Powdered TCC

The Full Catalogue

8 systems · 20 product lines

Jump to any system below — every product carries lab-certified chemistry and a downloadable data sheet.

System 01 · Service Zone · TUNDISH / LADLE MELT SURFACE

Steelmaking Consumables

Thermal cover systems for liquid steel - engineered to hold temperature from tap to cast and protect yield through every sequence.

Tundish Covering Compound — view 1

Specification Snapshot

Service zone
Tundish melt surface
Forms
Granular (INSULEX-GS) & Powder (INSULEX-PW)
Chemistries
Silica · Basic · Alumina/Neutral
Carbon
Carbon-free silica (<1.5%) to ULC (<= 0.2%)
Bulk density
0.55 - 1.0 g/cc (by grade)
Max service temp
up to 1650 degrees C

TCC forms a stable insulating crust over the tundish melt surface - cutting radiative heat loss, levelling superheat, absorbing non-metallic inclusions and shielding the steel from re-oxidation across multi-heat sequences. PIPL supplies it as carbon-free silica granules (PANCH INSULEX-GS) and fast-spreading powder (PANCH INSULEX-PW), with basic CaO-MgO, ultra-low-carbon (ULC) and alumina/neutral grades engineered to each plant's slag practice and tundish lining.

The PIPL Speciality

Unlike single-recipe imports, PIPL builds TCC in two physical forms - carbon-free silica granules (INSULEX-GS) and fast-spreading powder (INSULEX-PW) - across silica (acidic), basic CaO-MgO, alumina/neutral and ultra-low-carbon chemistries. Granules run low-dust and low-consumption; the basic grade (CaO 38-47%) saturates magnesia linings to extend tundish life; and the ULC grade (free carbon <= 0.2%) protects IF and clean steels from carbon pick-up. Every grade is lab-matched to your slag practice, not a catalogue average.

Why Engineers Choose It

  • Two forms - carbon-free silica granules (INSULEX-GS) & powder (INSULEX-PW)
  • Silica (acidic), basic CaO-MgO and alumina/neutral chemistries
  • Ultra-low-carbon grade (free C <= 0.2%) for IF & clean steels
  • Basic grade saturates magnesia linings to extend tundish life

Variants

  • INSULEX-GS · Granular Silica
  • INSULEX-GS · Granular Neutral
  • INSULEX-PW · Powder Silica
  • Basic · CaO-MgO
  • Basic · ULC (ultra-low carbon)
  • Alumina / Neutral

Applications

  • Continuous casting tundish thermal cover
  • Long sequence / multi-heat casting
  • Superheat & temperature uniformity control
  • Clean-steel, IF & ultra-low-carbon grade protection

Forms & Grades · 2 engineered forms

Supplied in Granular & Powdered

Carbon-free silica granules

PANCH INSULEX-GS is a carbon-free, silica-based covering compound in granular form. The granules charge with minimal dust and smoke for a clean, pollution-free platform, and run at a lower consumption rate than powder. Also available in a neutral chemistry to customer requirement.

Best for

Emission-controlled platforms · low consumption · clean handling

Swipe to compare grades →

PropertyINSULEX-GS · Silica (Acidic)
SiO2 (%)80 - 85
Al2O3 (%)5 - 8
R2O3 / Fe2O3 (%)4 - 8
Carbon, C (%)< 1.5
LOI (%)8 - 10
Moisture (%)< 3
Bulk Density (g/cc)0.55 - 0.65
Grain Size4 - 6 mm (90%)

System 02 · Service Zone · LIQUID STEEL COVER / LADLE NOZZLE

Natural & Specialized Compounds

Nature-derived insulation and precision free-opening compounds - circular-economy chemistry with steel-plant-grade consistency.

System 03 · Service Zone · LMF / CONTINUOUS CASTING MOULD

Metallurgical Aids

Process chemistry for cleaner steel - slag engineering aligned to LMF practice and mould flux tuned for high-speed casting.

System 04 · Service Zone · STEELMAKING VESSELS / CCM SEGMENTS

Monolithics & Engineered Components

High-strength refractory monolithics and precision ceramic components - long campaign life with fast maintenance turnaround.

System 05 · Service Zone · FURNACE / TUNDISH LINING

Shaped Refractories & Lining Solutions

Pre-cast pre-fired precision shapes and complete tundish lining systems - engineered to cut relining downtime to a minimum.

System 06 · Service Zone · LADLE / TUNDISH / BACKUP INSULATION

Ceramic Fibre & High Alumina Bricks

Very low-density ceramic fibre systems and high alumina bricks - from direct liquid-metal contact zones to backup insulation.

System 07 · Service Zone · LADLE → TUNDISH FLOW SYSTEM

Flow Control Refractories

The slide-gate flow-control train - precision nozzles, well blocks and gate plates that meter liquid steel from ladle to tundish to mould, change after change.

System 08 · Service Zone · INGOT / FOUNDRY FEEDING

Foundry & Feeding Aids

Exothermic and insulating feeding products for ingot moulds, risers and hot tops - higher casting yield with less metal lost to piping.

Need a spec sheet or
a plant trial?

Share your application and our metallurgy team will return full technical datasheets, MSDS, and a trial proposal.

Request Technical Data
